| Onderdeel nummer | NE133FHM-N56 |
| Merk | BOE |
| Maat | 13.3 |
| Sollicitatie | Laptop |
| Oplossing | 1920×1080 |
| Samenstelling | Oxide TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| merk | BOE |
| model | NE133FHM-N56 (BOE088C) |
| diagonale maat | 13.3 inch |
| type | Oxide TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1080 [FHD] 166PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 293.76(H)×165.24(V) mm |
| omtrek afm. | 298.76(H)×176.24(V) ×4.1(D) mm |
| bezel gebied | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| luminantie | 300 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedrijfsmodus | ADS, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M |
| lichtbron | WLED [11S4P] , 15K hours , W/O Driver |
| vorm stijl | Slim (PCBA Bent, T≤3.0mm) |
| ontworpen voor | Laptop |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 70 °C |
| B133XTN01.6 HW1A | AUO | 13.3 | 1366×768 |
| CLAA133WA01A | CPT | 13.3 | 1366×768 |
| LP133WD1-SLA1 | LG Display | 13.3 | 1600×900 |
| LP133WH2-SPA2 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLM2 | LG Display | 13.3 | 1366×768 |
| LQ133K1LA04 | SHARP | 13.3 | 1280×800 |
| LQ13X32 | SHARP | 13.3 | 1024×768 |
| LTN133AT01-003 | Samsung | 13.3 | 1280×800 |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| M133NWN1 R3 | IVO | 13.3 | 1366×768 |
