| Onderdeel nummer | N140HCA-EAC Rev.B1 |
| Merk | Innolux |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 1920×1080 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 700:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | |
| fabrikant | Innolux |
| modelnaam | N140HCA-EAC Rev.B1 |
| scherm grootte | 14.0 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 157PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 309.31 × 173.99 (H×V) |
| overzicht (mm) | 315.81 × 197.48 × 3 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 250 cd/m² (Typ.) |
| contrast ratio | 700 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 14/11 (Typ.)(Tr/Td) ms |
| goed zicht op | Symmetry |
| werk modus | AAS, Normally Black, Transmissive |
| kleuren diepte | 262K 45% NTSC |
| tegenlicht | WLED , 15K hours , With LED Driver |
| omlijnde vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruikt voor | Laptop |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
