| Onderdeel nummer | N133BGE-EA2 |
| Merk | Innolux |
| Maat | 13.3 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | eDP |
| fabrikant | Innolux |
| modelnaam | N133BGE-EA2 (CMN1393) |
| scherm grootte | 13.3 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1366(RGB)×768 (WXGA) 118PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 293.42 × 164.97 (H×V) |
| overzicht (mm) | 306.3 × 189.15 × 2.85 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 300 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| kijk hoek | 45/45/20/45 (Typ.)(CR≥10) |
| antwoord | 3/8 (Typ.)(Tr/Td) ms |
| goed zicht op | 6 o'clock |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | 262K 45% NTSC |
| tegenlicht | WLED , 15K hours , With LED Driver |
| omlijnde vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruikt voor | Laptop |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | eDP (1 Lane) , eDP1.2 , Connector 30 pins |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| N133B6-L01 | Innolux | 13.3 | 1366×768 |
| N133B6-L02 | Innolux | 13.3 | 1366×768 |
| N133BGE-E31 | Innolux | 13.3 | 1366×768 |
| N133BGE-E51 | Innolux | 13.3 | 1366×768 |
| N133BGE-EAB | Innolux | 13.3 | 1366×768 |
| N133BGE-EB1 | Innolux | 13.3 | 1366×768 |
| N133BGE-L21 | Innolux | 13.3 | 1366×768 |
| N133BGE-L31 | Innolux | 13.3 | 1366×768 |
| N133BGE-L41 | Innolux | 13.3 | 1366×768 |
| N133BGE-LB1 | Innolux | 13.3 | 1366×768 |
