| Onderdeel nummer | MV270QHB-N50 |
| Merk | BOE |
| Maat | 27.0 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 2560×1440 |
| Samenstelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | LVDS |
| paneel merk | BOE |
| paneelmodel | MV270QHB-N50 |
| paneel grootte | 27.0" |
| paneel type | a-Si TFT-LCD, CELL |
| oplossing | 2560(RGB)×1440, Quad-HD, 108PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 596.736(W)×335.664(H) mm |
| omlijsting openen | - |
| omtrek grootte | 607.736(W)×349.888(H) ×1.32(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 0 cd/m² |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| weergavemodus | ADS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 14 (Typ.)(G to G) |
| glas diepte | 0.50+0.50 mm |
| doorlaatbaarheid | 3.6% (Typ.)(with Polarizer) |
| kleuren weergeven | 16.7M 99% sRGB |
| soort lamp | No B/L |
| frequentie | 60Hz |
| touch screen | Without |
| bestuurder ic | COF Built-in 8 source chips |
| paneel gewicht | 650g (Typ.) |
| sollicitatie | Desktop Monitor |
| signaal interface | LVDS (4 ch, 8-bit) , 92 pins Connector |
| ingangsspanning | 5.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
