| Onderdeel nummer | MV230FHB-N10 |
| Merk | BOE |
| Maat | 23.0 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 1920×1080 |
| Samenstelling | CELL , a-Si TFT-LC |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | LVDS |
| fabrikant | BOE |
| modelnaam | MV230FHB-N10 |
| scherm grootte | 23.0 inch |
| scherm type | CELL , a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 95PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 509.184 × 286.416 (H×V) |
| overzicht (mm) | - |
| bezel gebied (mm) | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| luminantie | 0 cd/m² |
| contrast ratio | 1000 : 1 (Min.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 14 (Typ.)(G to G) ms |
| goed zicht op | Symmetry |
| werk modus | ADS, Normally Black, Transmissive |
| glas dikte | 0.50+0.50 mm |
| doorlaatbaarheid | - |
| kleuren diepte | 16.7M |
| tegenlicht | No B/L |
| massa | - |
| gebruikt voor | Desktop Monitor |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningsvoorziening | 5.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
