| Onderdeel nummer | MV185WHB-N20 |
| Merk | BOE |
| Maat | 18.5 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | LVDS |
| merk | BOE |
| model | MV185WHB-N20 |
| diagonale maat | 18.5 inch |
| type | a-Si TFT-LCD, CELL |
| pixel formaat | 1366(RGB)×768 [WXGA] 84PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 409.8(H)×230.4(V) mm |
| omtrek afm. | 422.2(H)×244.1(V) ×1.32(D) mm |
| bezel gebied | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| luminantie | 0 cd/m² |
| contrast ratio | 1000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 14 (Typ.)(G to G) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedrijfsmodus | HADS, Normally Black, Transmissive |
| plaatdikte | 0.50+0.50 mm |
| doorlaatbaarheid | 6.0% (Typ.)(with Polarizer) |
| ondersteunende kleur | 16.7M 72% NTSC |
| lichtbron | No B/L |
| gewicht | 327g (Typ.) |
| ontworpen voor | Desktop Monitor |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| d-ic detail | COF Built-in 2 source chips |
| interface-type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| stroomvoorziening | 5.0V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
