| Onderdeel nummer | MNE001EA1-1 |
| Merk | CSOT |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 3840×2160 |
| Samenstelling | LTPS TFT-LCD , LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| paneel merk | CSOT |
| paneel grootte | 14.0" |
| oplossing | 3840(RGB)×2160, UHD, 315PPI |
| weergavegebied | 309.31(W)×173.99(H) mm |
| helderheid | - |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 16.7M |
| frequentie | 60Hz |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| signaal interface | eDP Connector |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneelmodel | MNE001EA1-1 |
| paneel type | LTPS TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| contrast ratio | 1500:1 (Typ.) (TM) |
| weergavemodus | FFS, Normally Black, Transmissive |
| reactietijd | - |
| soort lamp | WLED |
| touch screen | - |
| sollicitatie | Laptop |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B140RW02 V0 | AUO | 14.0 | 1600×900 |
| B140XW02 V1 | AUO | 14.0 | 1366×768 |
| HB140WX1-200 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLA2 | LG Display | 14.0 | 1366×768 |
| LTN140AT02-C02 | Samsung | 14.0 | 1366×768 |
| LTN140AT16-401 | Samsung | 14.0 | 1366×768 |
| LTN140AT19-201 | Samsung | 14.0 | 1366×768 |
| N140BGE-L32 | Innolux | 14.0 | 1366×768 |
| N140HCE-EBA | Innolux | 14.0 | 1920×1080 |
