| Onderdeel nummer | MG1561B01-2 |
| Merk | CSOT |
| Maat | 15.6 |
| Sollicitatie | Digital Signage |
| Oplossing | 1920×1080 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 3000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | CSOT |
| modelnaam | MG1561B01-2 |
| scherm grootte | 15.6 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 141PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 344.16 × 193.59 (H×V) |
| overzicht (mm) | 351.86 × 206.332 × 6.31 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| luminantie | 250 cd/m² (Typ.) |
| contrast ratio | 3000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 30 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | VA, Normally Black, Transmissive |
| kleuren diepte | 16.7M 72% NTSC |
| tegenlicht | WLED , 15K hours , With LED Driver |
| massa | 530g (Typ.) |
| gebruikt voor | Digital Signage |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (2 ch, 8-bit) , Connector 40 pins |
| spanningsvoorziening | 12.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
