| Onderdeel nummer | MCT-G320240DTCW-151N |
| Merk | TRULY |
| Maat | 5.7 |
| Sollicitatie | Industrial |
| Oplossing | 320×240 |
| Samenstelling | CSTN-LCD , LCM |
| Helderheid | |
| CR | 45:1 |
| Kleuren | Color |
| Tegenlicht | CCFL |
| Koppel | Parallel |
| merk | TRULY |
| diagonale maat | 5.7 inch |
| pixel formaat | 320(RGB)×240 [QVGA] 70PPI |
| actief gebied | 115.18(H)×86.38(V) mm |
| bezel gebied | 119.18(H)×90.38(V) mm |
| luminantie | 220 cd/m² (Typ.) |
| richting bekijken | - |
| kijk hoek | 50/50/55/40 (Typ.)(CR≥10) |
| ondersteunende kleur | Color |
| gewicht | - |
| frame rate | - |
| interface-type | Parallel Data (1ch, 8-bit) , 16 pins Connector |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -10 ~ 60 °C |
| model | MCT-G320240DTCW-151N |
| type | CSTN-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 158.5(H)×109(V) ×9.2(D) mm |
| behandeling | - |
| contrast ratio | 45:1 (Typ.) (TM) |
| reactietijd | 215/110 (Typ.)(Tr/Td) |
| bedrijfsmodus | STN, Normally Black, Transmissive |
| lichtbron | CCFL [1 pcs] , 15K hours , W/O Driver |
| ontworpen voor | Industrial |
| aanraakpaneel | Without |
