| Onderdeel nummer | MCG156FDLAAQNN-AN20 |
| Merk | Kyocera |
| Maat | 15.6 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1080 |
| Samenstelling | LTPS TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.2M |
| Tegenlicht | WLED |
| Koppel | |
| paneel merk | Kyocera |
| paneel grootte | 15.6" |
| oplossing | 1920(RGB)×1080, FHD, 141PPI |
| weergavegebied | 344.16(W)×193.59(H) mm |
| omtrek grootte | 363.8(W)×215.9(H) ×9.8(D) mm |
| helderheid | 450 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 16.2M 73% NTSC |
| frequentie | 60Hz |
| gewicht | 1.05/1.09Kgs (Typ./Max.) |
| paneelmodel | MCG156FDLAAQNN-AN20 |
| paneel type | LTPS TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 347.06(W)×196.49(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | AWV, Normally Black, Transmissive |
| reactietijd | 13/12 (Typ.)(Tr/Td) |
| soort lamp | WLED , 50K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
