| Onderdeel nummer | M238KCJ-L5B |
| Merk | Innolux |
| Maat | 23.8 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 2560×1440 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | Innolux |
| diagonale maat | 23.8 inch |
| pixel formaat | 2560(RGB)×1440 [Quad-HD] 123PPI |
| actief gebied | 525.696(H)×295.704(V) mm |
| bezel gebied | - |
| luminantie | 300 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| ondersteunende kleur | 16.7M 95% DCI-P3 |
| gewicht | 2.40/2.52Kgs (Typ./Max.) |
| frame rate | 60Hz |
| interface-type | LVDS (4 ch, 8-bit) , 92 pins Connector |
| stroomvoorziening | 10.0V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | M238KCJ-L5B |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 536.3(H)×313.7(V) ×14.9(D) mm |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| reactietijd | 8/7 (Typ.)(Tr/Td) |
| bedrijfsmodus | AAS, Normally Black, Transmissive |
| lichtbron | WLED , 30K hours , W/O Driver |
| ontworpen voor | Desktop Monitor |
| aanraakpaneel | Without |
