| Onderdeel nummer | M140NWR8 R0 |
| Merk | IVO |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | eDP |
| paneel merk | IVO |
| paneel grootte | 14.0" |
| oplossing | 1366(RGB)×768, WXGA, 112PPI |
| weergavegebied | 309.399(W)×173.952(H) mm |
| helderheid | - |
| kijk hoek | 45/45/15/35 (Typ.)(CR≥10) |
| beste zicht op | 6 o'clock |
| kleuren weergeven | 262K |
| frequentie | 60Hz |
| vorm stijl | Slim (PCBA Bent, T≤3.0mm) |
| signaal interface | eDP (1 Lane) Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneelmodel | M140NWR8 R0 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 8 (Typ.)(Tr+Td) |
| soort lamp | WLED , 15K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Laptop |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| B140RTN01.0 | AUO | 14.0 | 1600×900 |
| HB140WX1-200 | BOE | 14.0 | 1366×768 |
| LP140WH4-TLN1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLP1 | LG Display | 14.0 | 1366×768 |
| M140NWR1 R0 | IVO | 14.0 | 1366×768 |
| M140NWR2 R0 | IVO | 14.0 | 1366×768 |
| M140NWR2 R1 | IVO | 14.0 | 1366×768 |
| M140NWR2 R2 | IVO | 14.0 | 1366×768 |
| M140NWR4 R2 | IVO | 14.0 | 1366×768 |
