| Onderdeel nummer | M090AWP4 R0 |
| Merk | IVO |
| Maat | 9.0 |
| Sollicitatie | Outdoor High Brightn |
| Oplossing | 800×480 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleuren | 262K |
| Tegenlicht | 8S3P |
| Koppel | Parallel |
| paneel merk | IVO |
| paneel grootte | 9.0" |
| oplossing | 800(RGB)×480, WVGA, 104PPI |
| weergavegebied | 198(W)×112.08(H) mm |
| omtrek grootte | 210.82(W)×126.96(H) ×6.4(D) mm |
| helderheid | 750 cd/m² (Typ.) |
| kijk hoek | 70/70/50/70 (Typ.)(CR≥10) |
| beste zicht op | 6 o'clock |
| kleuren weergeven | 262K 70% NTSC |
| frequentie | 60Hz |
| paneel gewicht | 251g (Max.) |
| signaal interface | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| ingangsspanning | 3.3/11.6/22/-7V (Typ.)(VCC/VDDA/VGH/VGL) |
| omgeving | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| paneelmodel | M090AWP4 R0 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 200.2(W)×114.28(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 700:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 12 (Typ.)(Tr+Td) |
| soort lamp | 8S3P WLED , 30K hours , Without Driver |
| touch screen | Without |
| sollicitatie | Outdoor High Brightness Automotive Display |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| G090VTN02.0 | AUO | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| T-55562D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
