| Onderdeel nummer | LTM238HP01 |
| Merk | SAMSUNG |
| Maat | 23.8 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 3000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | SAMSUNG |
| modelnaam | LTM238HP01 |
| scherm grootte | 23.8 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 92PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 527.04 × 296.46 (H×V) |
| overzicht (mm) | - |
| luminantie | - |
| contrast ratio | 3000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 14 (Typ.)(G to G) ms |
| goed zicht op | Symmetry |
| werk modus | PVA, Normally Black, Transmissive |
| kleuren diepte | 16.7M 72% NTSC |
| tegenlicht | WLED |
| massa | - |
| gebruikt voor | Desktop Monitor |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningsvoorziening | 5.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
