| Onderdeel nummer | LTF230AN01 |
| Merk | SAMSUNG |
| Maat | 23.0 |
| Sollicitatie | TV Sets |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 4000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | SAMSUNG |
| model | LTF230AN01 |
| diagonale maat | 23.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1366(RGB)×768 [WXGA] 68PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 508.152(H)×285.696(V) mm |
| omtrek afm. | - |
| luminantie | - |
| contrast ratio | 4000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 8 (Typ.)(G to G) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedrijfsmodus | PVA, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M 68% NTSC |
| lichtbron | WLED |
| gewicht | - |
| ontworpen voor | TV Sets |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| stroomvoorziening | 12.0V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
