| Onderdeel nummer | LT057AC47000 |
| Merk | Toshiba Mobile Displ |
| Maat | 5.7 |
| Sollicitatie | Industrial |
| Oplossing | 640×480 |
| Samenstelling | LTPS TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.2M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | Toshiba Mobile Display |
| model | LT057AC47000 |
| diagonale maat | 5.7 inch |
| type | LTPS TFT-LCD, LCM |
| pixel formaat | 640(RGB)×480 [VGA] 141PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 115.2(H)×86.4(V) mm |
| omtrek afm. | - |
| luminantie | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| richting bekijken | 12 o'clock |
| reactietijd | 15/25 (Typ.)(Tr/Td) |
| kijk hoek | 60/60/55/45 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K/16.2M |
| lichtbron | WLED , 70K hours |
| gewicht | - |
| ontworpen voor | Industrial |
| frame rate | - |
| aanraakpaneel | Without |
| interface-type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA057VG02 | Mitsubishi | 5.7 | 640×480 |
| AA057VG12 | Mitsubishi | 5.7 | 640×480 |
| CLAA057VC01CT | CPT | 5.7 | 640×480 |
| EL320.240.36 ET | Lumineq | 5.7 | 320×240 |
| KCG057QV1DB-G77 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G02 | Kyocera | 5.7 | 320×240 |
| KS3224ASTT-FW-X9 | Kyocera | 5.7 | 320×240 |
| LM057QB1T073 | SHARP | 5.7 | 320×240 |
| LT057AA34B00 | TOSHIBA | 5.7 | 320×240 |
| TM320240EGFWVSWD | Tianma | 5.7 | 320×240 |
