| Onderdeel nummer | LSM270HP05-G01 |
| Merk | SAMSUNG |
| Maat | 27.0 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 3000:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | LVDS |
| paneel merk | SAMSUNG |
| paneelmodel | LSM270HP05-G01 |
| paneel grootte | 27.0" |
| paneel type | a-Si TFT-LCD, CELL |
| oplossing | 1920(RGB)×1080, FHD, 81PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 597.888(W)×336.312(H) mm |
| omlijsting openen | - |
| omtrek grootte | 608.288(W)×348.037(H) ×1.16(D) mm |
| oppervlak | Antiglare (Haze 25%) |
| helderheid | 0 cd/m² |
| contrast ratio | 3000:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| weergavemodus | SPVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 21 (Typ.)(G to G) |
| glas diepte | 0.40+0.40 mm |
| doorlaatbaarheid | 4.25% (Typ.)(with Polarizer) |
| kleuren weergeven | 16.7M 70% NTSC |
| soort lamp | No B/L |
| frequentie | 60Hz |
| touch screen | Without |
| bestuurder ic | COFBuilt-in 6 source chips |
| paneel gewicht | 560g (Typ.) |
| sollicitatie | Desktop Monitor |
| signaal interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| ingangsspanning | 12.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
