| Onderdeel nummer | LSI490HN01-V |
| Merk | SAMSUNG |
| Maat | 49 |
| Sollicitatie | Digital Signage |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 4000:1 |
| Kleuren | 1.07B |
| Tegenlicht | No |
| Koppel | LVDS |
| merk | SAMSUNG |
| model | LSI490HN01-V |
| diagonale maat | 49 inch |
| type | a-Si TFT-LCD, CELL |
| pixel formaat | 1920(RGB)×1080 [FHD] 45PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 1073.78(H)×604(V) mm |
| omtrek afm. | 1083.78(H)×615.5(V) ×1.3(D) mm |
| bezel gebied | - |
| behandeling | Antiglare (Haze 25%), Hard coating (2H) |
| luminantie | 0 cd/m² |
| contrast ratio | 4000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 6 (Typ.)(G to G) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedrijfsmodus | SPVA, Normally Black, Transmissive |
| plaatdikte | 0.40+0.50 mm |
| doorlaatbaarheid | 6.79% (Typ.)(with Polarizer) |
| ondersteunende kleur | 1.07B 99% sRGB |
| lichtbron | No B/L |
| gewicht | 1.80±0.18Kgs |
| ontworpen voor | Digital Signage |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| d-ic detail | COF Built-in 6 source chips |
| interface-type | LVDS (2 ch, 10-bit) , 51 pins Connector |
| stroomvoorziening | 12.0V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
