| Onderdeel nummer | LSC320AN09-H |
| Merk | SAMSUNG |
| Maat | 32.0 |
| Sollicitatie | TV Sets |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 4000:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | LVDS |
| paneel merk | SAMSUNG |
| paneel grootte | 32.0" |
| oplossing | 1366×768(RGB), WXGA, 49PPI |
| weergavegebied | 697.685(W)×392.256(H) mm |
| omtrek grootte | 713(W)×410.5(H) ×1.3(D) mm |
| helderheid | 0 cd/m² |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| glas diepte | 0.50+0.50 mm |
| kleuren weergeven | 16.7M 69% NTSC |
| frequentie | 60Hz |
| bestuurder ic | COF Built-in 1 source chips |
| paneel gewicht | 800g (Typ.) |
| signaal interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| ingangsspanning | 12.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
| paneelmodel | LSC320AN09-H |
| paneel type | a-Si TFT-LCD , CELL |
| pixel formaat | RGB Horizontal Stripe |
| omlijsting openen | - |
| oppervlak | Antiglare (Haze 2%), Hard coating (2H) |
| contrast ratio | 4000:1 (Typ.) (TM) |
| weergavemodus | SVA, Normally Black, Transmissive |
| reactietijd | 20 (Typ.)(G to G) |
| doorlaatbaarheid | 6.9% (Typ.)(with Polarizer) |
| soort lamp | No B/L |
| touch screen | Without |
| sollicitatie | TV Sets |
