| Onderdeel nummer | LQ050A5AG03 |
| Merk | Sharp |
| Maat | 5.0 |
| Sollicitatie | Automotive Display |
| Oplossing | 320×234 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 60:1 |
| Kleuren | Full |
| Tegenlicht | 1 |
| Koppel | Analog |
| fabrikant | Sharp |
| modelnaam | LQ050A5AG03 |
| scherm grootte | 5.0 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 320(RGB)×234 79PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 102.124 × 74.763 (H×V) |
| overzicht (mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antireflection |
| luminantie | 320 cd/m² (Typ.) |
| contrast ratio | 60 : 1 (Typ.) (TM) |
| kijk hoek | 65/65/40/65 (Typ.)(CR≥5) |
| antwoord | 30/50 (Typ.)(Tr/Td) ms |
| goed zicht op | - |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | Full color |
| tegenlicht | 1 pcs CCFL , 10K hours , No Driver |
| massa | 180g (Max.) |
| gebruikt voor | Automotive Display |
| vernieuwingsfrequentie | - |
| touch screen | Without |
| signaal type | Analog RGB , Connector 22 pins |
| spanningsvoorziening | 8.0/-5.0V (Typ.)(VSH/VSL) |
| max. waarderingen | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
