| Onderdeel nummer | LP140WU1-SPA1 |
| Merk | LG Display |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 1920×1200 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| fabrikant | LG Display |
| modelnaam | LP140WU1-SPA1 |
| scherm grootte | 14.0 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1200 (WUXGA) 161PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 301.594 × 188.496 (H×V) |
| overzicht (mm) | - |
| bezel gebied (mm) | - |
| behandeling | Glare (Haze 0%) |
| luminantie | - |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | - |
| goed zicht op | Symmetry |
| werk modus | IPS, Normally Black, Transmissive |
| kleuren diepte | 16.7M |
| tegenlicht | WLED , With LED Driver |
| omlijnde vorm | Slim (PCBA Bent, T≤3.0mm) |
| gebruikt voor | Laptop |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | eDP , Connector |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
