| Onderdeel nummer | LP133UD1-SPA2 |
| Merk | LG Display |
| Maat | 13.3 |
| Sollicitatie | Laptop |
| Oplossing | 3840×2160 |
| Samenstelling | Oxide TFT-LCD , LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| merk | LG Display |
| diagonale maat | 13.3 inch |
| pixel formaat | 3840(RGB)×2160 [UHD] 332PPI |
| actief gebied | 293.76(H)×165.24(V) mm |
| bezel gebied | 296.56(H)×168.16(V) mm |
| luminantie | 340 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| ondersteunende kleur | 16.7M 72% NTSC |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| frame rate | 60Hz |
| interface-type | eDP (4 Lanes) , HBR2 (5.4G/lane) , 40 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | LP133UD1-SPA2 (LGD0588) |
| type | Oxide TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 299.46(H)×186.67(V) ×2.2(D) mm |
| behandeling | Glare (Haze 0%), Hard coating (3H) |
| contrast ratio | 1400:1 (Typ.) (TM) |
| reactietijd | 35 (Typ.)(Tr+Td) |
| bedrijfsmodus | IPS, Normally Black, Transmissive |
| lichtbron | WLED , 15K hours , With LED Driver |
| ontworpen voor | Laptop |
| aanraakpaneel | Without |
