| Onderdeel nummer | LP116WH8-SPA1 |
| Merk | LG Display |
| Maat | 11.6 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | eDP |
| fabrikant | LG Display |
| modelnaam | LP116WH8-SPA1 (LGD0500) |
| scherm grootte | 11.6 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1366(RGB)×768 (WXGA) 135PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 256.125 × 144 (H×V) |
| overzicht (mm) | 278 × 168 × 3.2 (H×V×D) |
| bezel gebied (mm) | 260.15 × 147.5 (H×V) |
| behandeling | Glare (Haze 0%) |
| luminantie | 250 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 35 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | IPS, Normally Black, Transmissive |
| kleuren diepte | 262K 48% NTSC |
| tegenlicht | WLED , 15K hours , With LED Driver |
| omlijnde vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruikt voor | Laptop |
| vernieuwingsfrequentie | 60Hz |
| touch screen | In-Cell Touch |
| signaal type | eDP (1 Lane) , HBR1 (2.7G/lane) , Connector 40 pins |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
