| Onderdeel nummer | LM238WR3-SSB1 |
| Merk | LG Display |
| Maat | 23.8 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 3840×2160 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1300:1 |
| Kleuren | 1.07B |
| Tegenlicht | 18S3P |
| Koppel | eDP |
| paneel merk | LG Display |
| paneelmodel | LM238WR3-SSB1 |
| paneel grootte | 23.8" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 3840(RGB)×2160, UHD, 185PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 525.658(W)×295.704(H) mm |
| omlijsting openen | - |
| omtrek grootte | 536.3(W)×313.9(H) ×12.9(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 350 cd/m² (Typ.) |
| contrast ratio | 1300:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| weergavemodus | IPS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 14 (Typ.)(G to G) |
| kleuren weergeven | 1.07B 100% sRGB |
| soort lamp | 18S3P WLED , 30K hours , Without Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | 1.61/1.69Kgs (Typ./Max.) |
| sollicitatie | Desktop Monitor |
| signaal interface | eDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector |
| ingangsspanning | 10.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
