| Onderdeel nummer | LM238WF2-SSKP |
| Merk | LG Display |
| Maat | 23.8 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 15S4P |
| Koppel | LVDS |
| paneel merk | LG Display |
| paneelmodel | LM238WF2-SSKP |
| paneel grootte | 23.8" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1920(RGB)×1080, FHD, 92PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 527.04(W)×296.46(H) mm |
| omlijsting openen | - |
| omtrek grootte | 535(W)×314.3(H) ×19.6(D) mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 250 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| weergavemodus | IPS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 14 (Typ.)(G to G) |
| kleuren weergeven | 16.7M 72% NTSC |
| soort lamp | 15S4P WLED , 30K hours |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | 2.56/2.68Kgs (Typ./Max.) |
| sollicitatie | Desktop Monitor |
| signaal interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| ingangsspanning | 5.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
