| Onderdeel nummer | LM230WF9-SSA1 |
| Merk | LG Display |
| Maat | 23.0 |
| Sollicitatie | Desktop Monitor |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | LG Display |
| model | LM230WF9-SSA1 |
| diagonale maat | 23.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1080 [FHD] 95PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 509.184(H)×286.416(V) mm |
| omtrek afm. | 516.984(H)×302.708(V) ×14.2(D) mm |
| bezel gebied | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| luminantie | 250 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 14 (Typ.)(G to G) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedrijfsmodus | IPS, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M 72% NTSC |
| lichtbron | WLED [14S4P] , 30K hours , W/O Driver |
| gewicht | 1.79/1.88Kgs (Typ./Max.) |
| ontworpen voor | Desktop Monitor |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
