| Onderdeel nummer | LM140GF1L02 |
| Merk | PANDA |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 2560×1600 |
| Samenstelling | LCM , Oxide TFT-LC |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| fabrikant | PANDA |
| scherm grootte | 14.0 inch |
| pixel nummer | 2560(RGB)×1600 (WQXGA) 215PPI |
| actief gebied (mm) | 301.824 × 188.64 (H×V) |
| bezel gebied (mm) | - |
| luminantie | 300 cd/m² (Typ.) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 71% NTSC |
| omlijnde vorm | Slim (PCBA Flat, T≤3.2mm) |
| vernieuwingsfrequentie | 60Hz |
| signaal type | eDP (2 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 30 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| modelnaam | LM140GF1L02 (NCP006A) 1 Compatible |
| scherm type | LCM , Oxide TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 306.824 × 205.84 × 2.4 (H×V×D) |
| behandeling | Antiglare (Haze 25%) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| werk modus | FFS, Normally Black, Transmissive |
| tegenlicht | WLED , 15K hours , With LED Driver |
| gebruikt voor | Laptop |
| touch screen | Without |
| B140XTN03.2 | AUO | 14.0 | 1366×768 |
| B140XTN03.5 | AUO | 14.0 | 1366×768 |
| BT140GW01 V.A | Innolux | 14.0 | 1366×768 |
| CLAA140WB01A | CPT | 14.0 | 1366×768 |
| HB140WX1-500 | BOE | 14.0 | 1366×768 |
| HSD140PNW1-B00 | HannStar | 14.0 | 1600×900 |
| LP140WH1-TLC3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP140WH6-TJA1 | LG Display | 14.0 | 1366×768 |
| N140B6-D11 | Innolux | 14.0 | 1366×768 |
