| Onderdeel nummer | LM116LF3L02 |
| Merk | PANDA |
| Maat | 11.6 |
| Sollicitatie | Pad & Tablet |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , Oxide TFT-LC |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | eDP |
| fabrikant | PANDA |
| modelnaam | LM116LF3L02 (NCP0000) |
| scherm grootte | 11.6 inch |
| scherm type | LCM , Oxide TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 190PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 256.32 × 144.18 (H×V) |
| overzicht (mm) | 268 × 168 × 3 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 300 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | FFS, Normally Black, Transmissive |
| kleuren diepte | 16.7M 100% sRGB |
| tegenlicht | WLED , 15K hours , With LED Driver |
| massa | 215g (Max.) |
| gebruikt voor | Pad & Tablet |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
