| Onderdeel nummer | LD550DUE-FJA1 |
| Merk | LG Display |
| Maat | 55 |
| Sollicitatie | Digital Signage |
| Oplossing | 1920×1080 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | LG Display |
| modelnaam | LD550DUE-FJA1 |
| scherm grootte | 55 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 40PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 1209.6 × 680.4 (H×V) |
| overzicht (mm) | - |
| luminantie | - |
| contrast ratio | 1200 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Min.)(CR≥10) |
| antwoord | 6 (Typ.)(G to G) ms |
| goed zicht op | Symmetry |
| werk modus | IPS, Normally Black, Transmissive |
| kleuren diepte | 16.7M 68% NTSC |
| tegenlicht | WLED , 30K hours , No Driver |
| massa | - |
| gebruikt voor | Digital Signage |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (2 ch, 8-bit) , Connector 51 pins |
| spanningsvoorziening | 12.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
