| Onderdeel nummer | LC650EQF-DKM1 |
| Merk | LG Display |
| Maat | 65 |
| Sollicitatie | TV Sets |
| Oplossing | 3840×2160 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1400:1 |
| Kleuren | 16.7M/1.07B |
| Tegenlicht | WLED |
| Koppel | V-by-One |
| fabrikant | LG Display |
| scherm grootte | 65 inch |
| pixel nummer | 3840(RGB)×2160 (UHD) 68PPI |
| actief gebied (mm) | 1428.48 × 803.52 (H×V) |
| bezel gebied (mm) | - |
| luminantie | 400 cd/m² (Typ.) |
| kijk hoek | 89/89/89/89 (Min.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M/1.07B 84% NTSC |
| massa | 20.8/21.9Kgs (Typ./Max.) |
| vernieuwingsfrequentie | 120Hz |
| signaal type | V-by-One 16 lane , 92 pins Connector |
| spanningsvoorziening | 12.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| modelnaam | LC650EQF-DKM1 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 1452.1 × 827.83 (H×V×D) |
| behandeling | Antiglare (Haze 3%), Hard coating (2H) |
| contrast ratio | 1400 : 1 (Typ.) (TM) |
| antwoord | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) ms |
| werk modus | IPS, Normally Black, Transmissive |
| tegenlicht | WLED , 30K hours , No Driver |
| gebruikt voor | TV Sets |
| touch screen | Without |
