| Onderdeel nummer | LC550EQH-DJF1 |
| Merk | LG Display |
| Maat | 55 |
| Sollicitatie | TV Sets |
| Oplossing | 3840×2160 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleuren | 1.06B |
| Tegenlicht | WLED |
| Koppel | EPI |
| merk | LG Display |
| model | LC550EQH-DJF1 |
| diagonale maat | 55 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 3840(RGB)×2160 [UHD] 80PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 1209.6(H)×680.4(V) mm |
| omtrek afm. | 1239.8(H)×716.3(V) ×27.8(D) mm |
| bezel gebied | - |
| behandeling | Antiglare (Haze 3%), Hard coating (2H) |
| luminantie | 400 cd/m² (Typ.) |
| contrast ratio | 1400:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 8/10 (Typ.)(Tr/Td) |
| kijk hoek | 89/89/89/89 (Min.)(CR≥10) |
| bedrijfsmodus | IPS, Normally Black, Transmissive |
| ondersteunende kleur | 1.06B 82% NTSC |
| lichtbron | WLED , 30K hours , W/O Driver |
| gewicht | 13.7/14.4Kgs (Typ./Max.) |
| ontworpen voor | TV Sets |
| frame rate | 120Hz |
| aanraakpaneel | Without |
| interface-type | EPI , 160 pins Connector |
| stroomvoorziening | 12.0V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
