| Onderdeel nummer | LC550EQF-YJF1 |
| Merk | LG Display |
| Maat | 55 |
| Sollicitatie | TV Sets |
| Oplossing | 3840×2160 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleuren | 16.7M/1.06B |
| Tegenlicht | WLED |
| Koppel | V-by-One |
| paneel merk | LG Display |
| paneelmodel | LC550EQF-YJF1 |
| paneel grootte | 55" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 3840(RGB)×2160, UHD, 80PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 1209.6(W)×680.4(H) mm |
| omlijsting openen | - |
| omtrek grootte | 1232.2(W)×708.6(H) ×50.1(D) mm |
| oppervlak | Antiglare (Haze 3%), Hard coating (2H) |
| helderheid | 500 cd/m² (Typ.) |
| contrast ratio | 1400:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Min.)(CR≥10) |
| weergavemodus | IPS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) |
| kleuren weergeven | 16.7M/1.06B 87% NTSC |
| soort lamp | WLED , 30K hours , Without Driver |
| frequentie | 120Hz |
| touch screen | Without |
| paneel gewicht | 12.5/13.2Kgs (Typ.) |
| sollicitatie | TV Sets |
| signaal interface | V-by-One 16 lane , 97 pins Connector |
| ingangsspanning | 12.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LC550EQD-FGF4 | LG Display | 55 | 3840×2160 |
| LC550EQE-PGF1 | LG Display | 55 | 3840×2160 |
| LC550EQE-PHF1 | LG Display | 55 | 3840×2160 |
| LC550EUE-SEM1 | LG Display | 55 | 1920×1080 |
| LC550EUF-FEP1 | LG Display | 55 | 1920×1080 |
| LC550EUF-FGF1 | LG Display | 55 | 1920×1080 |
| LC550EUG-KEF1 | LG Display | 55 | 1920×1080 |
| LC550EUH-RDA2 | LG Display | 55 | 1920×1080 |
| LC550EUN-FFM1 | LG Display | 55 | 1920×1080 |
| LC550EUN-SFF1 | LG Display | 55 | 1920×1080 |
