| Onderdeel nummer | LC470EUG-PEF2 |
| Merk | LG Display |
| Maat | 47 |
| Sollicitatie | TV Sets |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleuren | 1.06B |
| Tegenlicht | WLED |
| Koppel | EPI |
| paneel merk | LG Display |
| paneelmodel | LC470EUG-PEF2 |
| paneel grootte | 47" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1920(RGB)×1080, FHD, 46PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 1039.68(W)×584.82(H) mm |
| omlijsting openen | - |
| omtrek grootte | 1059.5(W)×616.2(H) mm |
| oppervlak | Antiglare (Haze 1%), Hard coating (2H) |
| helderheid | 360 cd/m² (Typ.) |
| contrast ratio | 1400:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Min.)(CR≥10) |
| weergavemodus | S-IPS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 8/10 (Typ.)(Tr/Td) |
| kleuren weergeven | 1.06B 68% NTSC |
| soort lamp | WLED , 50K hours , Without Driver |
| frequentie | 120Hz |
| touch screen | Without |
| paneel gewicht | 10.5/11.0Kgs (Typ./Max.) |
| sollicitatie | TV Sets |
| signaal interface | EPI , 100 pins Connector |
| ingangsspanning | 12.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LC470EUE-SEM2 | LG Display | 47 | 1920×1080 |
| LC470EUF-FEP1 | LG Display | 47 | 1920×1080 |
| LC470EUF-PEF1 | LG Display | 47 | 1920×1080 |
| LC470EUF-SDF1 | LG Display | 47 | 1920×1080 |
| LC470EUF-SDF2 | LG Display | 47 | 1920×1080 |
| LC470EUH-LFF1 | LG Display | 47 | 1920×1080 |
| LC470EUH-PFP1 | LG Display | 47 | 1920×1080 |
| LC470EUN-FEF1 | LG Display | 47 | 1920×1080 |
| LC470EUN-SDF1 | LG Display | 47 | 1920×1080 |
| LC470EUN-SFM1 | LG Display | 47 | 1920×1080 |
