| Onderdeel nummer | LC156LF1L03 |
| Merk | PANDA |
| Maat | 15.6 |
| Sollicitatie | Laptop |
| Oplossing | 1920×1080 |
| Samenstelling | Oxide TFT-LCD, CELL |
| Helderheid | |
| CR | - |
| Kleuren | 262K |
| Tegenlicht | No |
| Koppel | eDP |
| paneel merk | PANDA |
| paneelmodel | LC156LF1L03 |
| paneel grootte | 15.6" |
| paneel type | Oxide TFT-LCD, CELL |
| oplossing | 1920(RGB)×1080, FHD, 141PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 344.16(W)×193.59(H) mm |
| omlijsting openen | - |
| omtrek grootte | 354.36(W)×204.04(H) ×1.076(D) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| helderheid | 0 cd/m² |
| contrast ratio | - |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | FFS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 25 (Typ.)(Tr+Td) |
| glas diepte | 0.40+0.40 mm |
| doorlaatbaarheid | 6.5% (Typ.) |
| kleuren weergeven | 262K 47% NTSC |
| soort lamp | No B/L , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| bestuurder ic | COGBuilt-in 4 source + 2 gate chips |
| vorm stijl | - |
| sollicitatie | Laptop |
| signaal interface | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
