| Onderdeel nummer | LA123WF1-SR02 |
| Merk | LG Display |
| Maat | 12.3 |
| Sollicitatie | Automotive Display |
| Oplossing | 1920×720 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | RSDS |
| merk | LG Display |
| diagonale maat | 12.3 inch |
| pixel formaat | 1920(RGB)×720 167PPI |
| actief gebied | 292.032(H)×109.512(V) mm |
| bezel gebied | - |
| luminantie | 600 cd/m² (Min.) |
| richting bekijken | Symmetry |
| kijk hoek | 89/89/89/89 (Min.)(CR≥10) |
| ondersteunende kleur | 16.7M 86% NTSC |
| gewicht | 390/405g (Typ./Max.) |
| frame rate | 60Hz |
| interface-type | RSDS (2 Channel) , 110 pins FPC |
| stroomvoorziening | 3.3/13.0V (Typ.)(VCC/VDD) |
| omgeving | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| model | LA123WF1-SR02 |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 310(H)×128(V) ×11.05(D) mm |
| behandeling | Antiglare, Antireflection |
| contrast ratio | 800:1 (Min.) (TM) |
| reactietijd | 30 (Typ.)(Tr+Td) |
| bedrijfsmodus | IPS, Normally Black, Transmissive |
| lichtbron | WLED [8S6P] , 10K hours , W/O Driver |
| ontworpen voor | Automotive Display |
| aanraakpaneel | Without |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
