| Onderdeel nummer | LA084X02-SL01 |
| Merk | LG Display |
| Maat | 8.4 |
| Sollicitatie | Automotive Display |
| Oplossing | 1024×768 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.2M |
| Tegenlicht | 10S3P |
| Koppel | LVDS |
| fabrikant | LG Display |
| modelnaam | LA084X02-SL01 |
| scherm grootte | 8.4 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1024(RGB)×768 (XGA) 152PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 170.496 × 127.872 (H×V) |
| overzicht (mm) | 184.5 × 143 × 9.95 (H×V×D) |
| luminantie | 1200 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Min.)(CR≥10) |
| antwoord | 40 (Max.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | IPS, Normally Black, Transmissive |
| kleuren diepte | 16.2M 70% NTSC |
| tegenlicht | 10S3P WLED , No Driver |
| massa | 255/260g (Typ./Max.) |
| gebruikt voor | Automotive Display |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (1 ch, 8-bit) , FPC 40 pins |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.84G (27.8 m/s²) |
| AA084VB01 | Mitsubishi | 8.4 | 640×480 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| LQ9D01C | SHARP | 8.4 | 640×480 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| LTM08C355S | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-25 | NLT | 8.4 | 640×480 |
