| Onderdeel nummer | KG057QV1EB-G000 |
| Merk | Kyocera |
| Maat | 5.7 |
| Sollicitatie | Industrial |
| Oplossing | 320×240 |
| Samenstelling | STN-LCD, LCM |
| Helderheid | |
| CR | 4:1 |
| Kleuren | Monochrome |
| Tegenlicht | CCFL |
| Koppel | |
| paneel merk | Kyocera |
| paneelmodel | KG057QV1EB-G000 |
| paneel grootte | 5.7" |
| paneel type | STN-LCD, LCM |
| oplossing | 320×240, QVGA, 70PPI |
| pixel formaat | Rectangle |
| weergavegebied | 115.18(W)×86.38(H) mm |
| omlijsting openen | - |
| helderheid | - |
| contrast ratio | 4:1 (Typ.) (TM) |
| kijk hoek | 45/45/20/40 (Typ.)(CR≥2) |
| weergavemodus | STN, Blue mode (Negative), Transmissive |
| beste zicht op | - |
| reactietijd | 380/120 (Typ.)(Tr/Td) |
| kleuren weergeven | Monochrome |
| soort lamp | CCFL |
| frequentie | - |
| touch screen | Without |
| paneel gewicht | - |
| sollicitatie | Industrial |
| omgeving | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| KG057QV1CA-G00 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G000 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G01 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G02 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G020 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G020W | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G03 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G04 | Kyocera | 5.7 | 320×240 |
| KG057QV1CF-G050 | Kyocera | 5.7 | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
