| Onderdeel nummer | KCS057QV1BH-G20 |
| Merk | Kyocera |
| Maat | 5.7 |
| Sollicitatie | Industrial |
| Oplossing | 320×240 |
| Samenstelling | LCM, CSTN-LCD |
| Helderheid | |
| CR | 40:1 |
| Kleuren | Color |
| Tegenlicht | 1 |
| Koppel | Parallel |
| fabrikant | Kyocera |
| modelnaam | KCS057QV1BH-G20 |
| scherm grootte | 5.7 inch |
| scherm type | LCM, CSTN-LCD |
| pixel nummer | 320(RGB)×240 (QVGA) 70PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 115.2 × 86.4 (H×V) |
| overzicht (mm) | - |
| luminantie | - |
| contrast ratio | 40 : 1 (Typ.) (TM) |
| kijk hoek | 50/50/30/30 (Typ.)(CR≥2) |
| antwoord | 220/110 (Typ.)(Tr/Td) ms |
| goed zicht op | - |
| werk modus | STN, Normally Black, Transmissive |
| kleuren diepte | Color |
| tegenlicht | 1 pcs CCFL , 40K hours , No Driver |
| massa | - |
| gebruikt voor | Industrial |
| vernieuwingsfrequentie | - |
| touch screen | Without |
| signaal type | Parallel Data (1ch, 8-bit) , Connector 15 pins |
