| Onderdeel nummer | JJ070IA-18L |
| Merk | Innolux |
| Maat | 7.0 |
| Sollicitatie | Automotive Display |
| Oplossing | 800×480 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 7S2P |
| Koppel | LVDS |
| fabrikant | Innolux |
| scherm grootte | 7.0 inch |
| pixel nummer | 800(RGB)×480 (WVGA) 133PPI |
| actief gebied (mm) | 152.4 × 91.44 (H×V) |
| bezel gebied (mm) | 155.4 × 94.44 (H×V) |
| luminantie | 750 cd/m² (Typ.) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 70% NTSC |
| massa | 195±9g |
| vernieuwingsfrequentie | 60Hz |
| signaal type | LVDS (1 ch, 8-bit) , 50 pins FPC |
| spanningsvoorziening | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| max. waarderingen | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| modelnaam | JJ070IA-18L |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 162.8 × 104.84 (H×V×D) |
| behandeling | Antiglare |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| antwoord | 15/10 (Typ.)(Tr/Td) ms |
| werk modus | IPS, Normally Black, Transmissive |
| tegenlicht | 7S2P WLED , 20K hours , No Driver |
| gebruikt voor | Automotive Display |
| touch screen | Without |
