| Onderdeel nummer | HV650QUB-F9A |
| Merk | BOE |
| Maat | 65 |
| Sollicitatie | TV Sets |
| Oplossing | 3840×2160 |
| Samenstelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 1.07B |
| Tegenlicht | No |
| Koppel | V-by-One |
| merk | BOE |
| model | HV650QUB-F9A |
| diagonale maat | 65 inch |
| type | a-Si TFT-LCD, CELL |
| pixel formaat | 3840(RGB)×2160 [UHD] 68PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 1428.48(H)×803.52(V) mm |
| omtrek afm. | 1438.48(H)×815.02(V) mm |
| bezel gebied | - |
| behandeling | Antiglare (Haze 1%) |
| luminantie | 0 cd/m² |
| contrast ratio | 1200:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 8 (Typ.)(G to G) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedrijfsmodus | ADS, Normally Black, Transmissive |
| plaatdikte | 0.50+0.50 mm |
| doorlaatbaarheid | 5.1% (Typ.)(with Polarizer) |
| ondersteunende kleur | 1.07B 99% sRGB |
| lichtbron | No B/L |
| gewicht | TBD |
| ontworpen voor | TV Sets |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| d-ic detail | COF Built-in 12 source chips |
| interface-type | V-by-One 8 lane , 51 pins Connector |
| stroomvoorziening | 12.0V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
