| Onderdeel nummer | HSD156JUW2-A10 |
| Merk | HannStar |
| Maat | 15.6 |
| Sollicitatie | Outdoor High Brightn |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 4 |
| Koppel | |
| fabrikant | HannStar |
| scherm grootte | 15.6 inch |
| pixel nummer | 1920(RGB)×1080 (FHD) 141PPI |
| actief gebied (mm) | 344.16 × 193.59 (H×V) |
| bezel gebied (mm) | - |
| luminantie | 850 (Typ.)(cd/m²) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 70% |
| massa | TBD |
| vernieuwingsfrequentie | 60Hz |
| modelnaam | HSD156JUW2-A10 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 363.7 × 215.7 (H×V×D) |
| behandeling | Hard coating |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| werk modus | IPS Pro, Normally Black, Transmissive |
| antwoord | 15/15 (Max.)(Tr+Td) ms |
| tegenlicht | 4 strings WLED , 30K hours , No Driver |
| gebruikt voor | Outdoor High Brightness Automotive Display |
| touch screen | Without |
