| Onderdeel nummer | HSD156JUW1-A00 |
| Merk | HannStar |
| Maat | 15.6 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 8S6P |
| Koppel | LVDS |
| fabrikant | HannStar |
| modelnaam | HSD156JUW1-A00 |
| scherm grootte | 15.6 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 141PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 344.16 × 193.59 (H×V) |
| overzicht (mm) | 363.8 × 215.9 × 12 (H×V×D) |
| bezel gebied (mm) | 346 × 195.4 (H×V) |
| behandeling | Antiglare |
| luminantie | 850 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 18/17 (Typ.)(Tr/Td) ms |
| goed zicht op | Symmetry |
| werk modus | IPS Pro, Normally Black, Transmissive |
| kleuren diepte | 16.7M 70% NTSC |
| tegenlicht | 8S6P WLED , 50K hours , With LED Driver |
| massa | TBD |
| gebruikt voor | Industrial Outdoor High Brightness Automotive Display |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningsvoorziening | 5.0V (Typ.) |
| max. waarderingen | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
