| Onderdeel nummer | HSD121KXN1-B00-C10 |
| Merk | HannStar |
| Maat | 12.1 |
| Sollicitatie | Automotive Display |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| paneel merk | HannStar |
| paneel grootte | 12.1" |
| oplossing | 1024(RGB)×768, XGA, 105PPI |
| weergavegebied | 245.76(W)×184.32(H) mm |
| helderheid | 600 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 16.7M 72% NTSC |
| frequentie | 60Hz |
| gewicht | - |
| paneelmodel | HSD121KXN1-B00-C10 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| contrast ratio | 900:1 (Typ.) (TM) |
| weergavemodus | IPS Pro, Normally Black, Transmissive |
| reactietijd | 30 (Typ.)(Tr+Td) |
| soort lamp | WLED , 30K hours , With LED Driver |
| touch screen | Embeded Touch |
| sollicitatie | Automotive Display |
