| Onderdeel nummer | HSD090JFW1-A02 |
| Merk | HannStar |
| Maat | 9.0 |
| Sollicitatie | Automotive Display |
| Oplossing | 1024×600 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.2M |
| Tegenlicht | 3S13P |
| Koppel | LVDS |
| fabrikant | HannStar |
| modelnaam | HSD090JFW1-A02 |
| scherm grootte | 9.0 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1024(RGB)×600 (WSVGA) 132PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 196.608 × 114.15 (H×V) |
| overzicht (mm) | 211.1 × 126.5 × 6 (H×V×D) |
| bezel gebied (mm) | 200.01 × 117.55 (H×V) |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 500 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 17/18 (Typ.)(Tr/Td) ms |
| goed zicht op | Symmetry |
| werk modus | IPS Pro, Normally Black, Transmissive |
| kleuren diepte | 16.2M 50% NTSC |
| tegenlicht | 3S13P WLED , 15K hours , No Driver |
| massa | 226g (Typ.) |
| gebruikt voor | Automotive Display |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (1 ch, 8-bit) , FPC 40 pins |
| spanningsvoorziening | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
