| Onderdeel nummer | GV185FHM-N10-DM30 |
| Merk | BOE |
| Maat | 18.5 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 11S4P |
| Koppel | LVDS |
| paneel merk | BOE |
| paneelmodel | GV185FHM-N10-DM30 |
| paneel grootte | 18.5" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1920(RGB)×1080, FHD, 119PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 408.96(W)×230.04(H) mm |
| omlijsting openen | 410.96(W)×232.04(H) mm |
| omtrek grootte | 430.4(W)×254.6(H) ×12.5(D) mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 350 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | ADS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.7M 70% NTSC |
| soort lamp | 11S4P WLED , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | 1.80Kgs (Typ.) |
| sollicitatie | Industrial |
| signaal interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| ingangsspanning | 5.0V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| LM185TT1A | PANDA | 18.5 | 1366×768 |
| LM185TT2A | PANDA | 18.5 | 1366×768 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| M185B1-L07 | Innolux | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185XTN01.3 | AUO | 18.5 | 1366×768 |
| M185XW01 V2 | AUO | 18.5 | 1366×768 |
| M185XW01 V5 | AUO | 18.5 | 1366×768 |
| M185XW01 V6 | AUO | 18.5 | 1366×768 |
| MT185GW01 V.0 | Innolux | 18.5 | 1366×768 |
