| Onderdeel nummer | GV185FHM-N10-3M30 |
| Merk | BOE |
| Maat | 18.5 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | BOE |
| model | GV185FHM-N10-3M30 |
| diagonale maat | 18.5 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1080 [FHD] 119PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 408.96(H)×230.04(V) mm |
| omtrek afm. | 430.4(H)×254.6(V) ×12.5(D) mm |
| bezel gebied | 410.96(H)×232.04(V) mm |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| luminantie | 350 cd/m² (Typ.) |
| contrast ratio | 1200:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| bedrijfsmodus | ADS, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M 70% NTSC |
| lichtbron | WLED [11S4P] , With LED Driver |
| gewicht | 1.80Kgs (Typ.) |
| ontworpen voor | Industrial |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| stroomvoorziening | 5.0V (Typ.) |
| omgeving | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
