| Onderdeel nummer | GT101WSM-N10 |
| Merk | BOE |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 4 |
| Koppel | |
| paneel merk | BOE |
| paneel grootte | 10.1" |
| oplossing | 1024(RGB)×600, WSVGA, 117PPI |
| weergavegebied | 222.72(W)×125.28(H) mm |
| omtrek grootte | 235(W)×143(H) mm |
| helderheid | 350 cd/m² (Typ.) |
| kijk hoek | 70/70/0/60 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K/16.7M 50% NTSC |
| frequentie | 60Hz |
| gewicht | 180g (Typ.) |
| paneelmodel | GT101WSM-N10 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 225.92(W)×128.48(H) mm |
| oppervlak | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 20 (Typ.)(Tr+Td) |
| soort lamp | 4 strings WLED , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
