| Onderdeel nummer | G270QAN02.0 |
| Merk | AUO |
| Maat | 27.0 |
| Sollicitatie | Industrial |
| Oplossing | 2560×1440 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 4 |
| Koppel | LVDS |
| fabrikant | AUO |
| modelnaam | G270QAN02.0 |
| scherm grootte | 27.0 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 2560(RGB)×1440 (Quad-HD) 108PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 596.74 × 335.66 (H×V) |
| overzicht (mm) | 606.44 × 355.56 × 15.03 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 350 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 8/8 (Typ.)(Tr/Td) ms |
| goed zicht op | Symmetry |
| werk modus | AHVA, Normally Black, Transmissive |
| kleuren diepte | 16.7M 99% sRGB |
| tegenlicht | 4 strings WLED , 30K hours , No Driver |
| massa | 3.50Kgs (Typ.) |
| gebruikt voor | Industrial |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (4 ch, 8-bit) , 70 pins Connector |
| spanningsvoorziening | 5.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 55 °C Operating Temp.: 0 ~ 50 °C |
