| Onderdeel nummer | G270HAN01.2 |
| Merk | AUO |
| Maat | 27.0 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1080 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 22S4P |
| Koppel | LVDS |
| fabrikant | AUO |
| modelnaam | G270HAN01.2 |
| scherm grootte | 27.0 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 81PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 597.888 × 336.312 (H×V) |
| overzicht (mm) | 611.48 × 355.81 × 13.3 (H×V×D) |
| bezel gebied (mm) | 601.49 × 339.91 (H×V) |
| behandeling | Antiglare |
| luminantie | 400 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 14 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | AHVA, Normally Black, Transmissive |
| kleuren diepte | 16.7M 72% NTSC |
| tegenlicht | 22S4P WLED , 50K hours , No Driver |
| massa | 2.87Kgs (Typ.) |
| gebruikt voor | Industrial |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (2 ch, 8-bit) , Connector 30 pins |
| spanningsvoorziening | 5.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
