| Onderdeel nummer | G270HAN01.0 |
| Merk | AUO |
| Maat | 27.0 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 1.07B |
| Tegenlicht | WLED |
| Koppel | LVDS |
| paneel merk | AUO |
| paneelmodel | G270HAN01.0 |
| paneel grootte | 27.0" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1920(RGB)×1080, FHD, 81PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 597.888(W)×336.312(H) mm |
| omlijsting openen | 602(W)×340.4(H) mm |
| omtrek grootte | 630(W)×368.2(H) ×23.4(D) mm |
| oppervlak | Antiglare |
| helderheid | 1000 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| weergavemodus | AHVA, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 14 (Typ.)(Tr+Td) |
| kleuren weergeven | 1.07B 87% NTSC |
| soort lamp | WLED , 50K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | 3.40Kgs (Typ.) |
| sollicitatie | Industrial Outdoor High Brightness |
| signaal interface | LVDS , 51 pins Connector |
| ingangsspanning | 12.0V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
